The InterValve Bellow Sealed valves have been solving fluid control problems in Steam, Boiling and other general industrial applications for over 30 years. Today InterValve Technologies is putting that experience to work for you in more ways than ever before- meeting your changing needs with dependable InterValve Bellow valves and accessories.
Bellow Sealed Globe Valve, one type of specially designed Globe Valve by InterValve , which is Applicable for the Cutting and Connection of Pipelines Medium That are Used in Various Industries Such as Petroleum, Chemical, Pharmacy, Chemical Fertilizer and Electric Power Plants etc under Nominal Pressures from PN1.6Mpa to PN4.0Mpa and Working Temperatures from -20C to 350C Degree.
InterValve BELLOW SEALED VALVE MAIN DESIGNING FEATURES
Bellow sealed Globe valves manufactured and supplied by InterValve are with Reasonable Structure, Reliable Sealing, Excellent Performance and Beautiful Appearance
» BROAD MATERIAL AVAILABILITY: Providing with the various Cast body and Trim materials, the InterValve Bellow Valve often provides the most economical solution for your process and Steaming system.
» Sealing Surface: Hard-facing with Cr. Alloy which is Anti-resistant, Corrosion-resistant, Anti-Friction to Ensure a Longer Service Life. Tight shut-off Double Sealing to Ensure a Perfect Operation.
» STEM: Quenched and Tempered with Nitriding Treatment Which Ensure A Perfect Anti-corrosion and Anti-friction Features.
» OPTIONAL Stem Position Indicator: To Show More Directly on the Valve On/Off Status.
STANDARDS COMPLIANCE:
» DIN 3356, BS 5160, ASME B16.34, API 602
» ASME B16.10, EN558-1 / DIN 3202
» ASME B16.5, ASME B16.11, ASME B1.20.1, DIN 2543~2545, EN 12627
» ISO 5208, API 598, DIN 3230, MSS SP-117
» Sizes: DN15 through DN400
» Body Styles: End connections Flanged, Welded or Threaded Ends
» Pressure Class: ANSI CL150 to CL900, PN16 to PN64.
» Actuations: Handwheel, Electric, Pneumatic, Hydraulic or E-Hydraulic
